AIR-62 IP is a Weather-resistant speaker with extremely compact size, compact weight and numerous mounting options. AIR-62 IP features 6” woofer with 1,75” voice coil and is availabe in 8 and 16 Ohm versions.
Product description:
Weather-resistant speaker
Main features:
• 150 W nominal power
• 6” woofer with 1,75” voice coil
• 1” HF driver with 1” voice coil
• 124 dB Max SPL
• VESA 75x75, M10 mounting points
Specification
| Main | |
|---|---|
| Type | Weather-resistant speaker |
| Acoustical & Electrical data | |
| Frequency response (-10dB) | 90 - 18000 Hz |
| Max SPL 1 | 124 dB |
| Sensitivity (1W/1m) | 93 dB |
| LF Driver | 6", 1,75" VC |
| HF Driver | 1", 1" VC |
| Nominal Coverage Angle (Horizontal × Vertical) | 80 x 60 deg |
| Impedance | 8 / 16 Ohm |
| Nominal power 2 | 150 W |
| Connectors | Phoenix |
| Connections and physical data | |
| Dimensions (W x H x D) | 270 x 356 x 233 mm |
| Net weight | 6 kg |
| Shipping weight | 7 kg |
| Mounting | VESA 75 x 75; 2 x M10 Mounting points; M10 safety point |
| Weather protection | IP 54 weather-protection |
| Enclosure material | Plywood; wear-resistant paint |
| Speaker protection | Steel grill, acoustically transparent backing |
