Focus 5 - passive stage monitor based on 15’’ LF coaxial driver. The system is a must-have for every performer who values comfort and clearly focused sound picture at the stage. To increase system’s usability, Focus 5 has been created compatible with distance pole adapters so it can be used as well for DJ monitoring, backline and even FOH purposes.
Product description:
Passive stage monitor
Main features:
- 500W nominal power
- 15” coaxial driver
- 137 dB Peak SPL
- Pole mount adapter
Specifications
| Main | |
|---|---|
| Type | Passive stage monitor |
| Acoustical & Electrical data | |
| Frequency response (-10dB) |
|
| Peak SPL 1 | 137 dB |
| Sensitivity (1W/1m) | 98 dB |
| Coaxial driver | 15”, 3" / 2,8" VC |
| Nominal Coverage Angle (Horizontal × Vertical) | 40° x 80° |
| Impedance | 8 Ohm LF / 8 Ohm HF |
| Nominal power 2 | 500 W LF |
| Nominal power (in detail) 2 | 500 W LF / 100 W HF |
| Connectors | 2 x Neutrik Speakon |
| Connections and physical data | |
| Dimensions (W x H x D) | 590 x 360 x 541 mm |
| Net weight | 21,4 kg |
| Shipping weight | 22,4 kg |
| Mounting | 35 mm distance pole adapter, angle raisers, feet rubber |
| Enclosure material | Plywood; wear-resistant paint |
| Grill | Steel grill, acoustically transparent backing |
